3M Ultra S 800
3M™ Safety & Security Window Film
Maximum protection demands maximum engineering. 3M™ Scotchshield™ Ultra S800 features proprietary micro-layered film technology — unlike conventional safety films that rely on thickness alone, Ultra S800 is constructed with hundreds of micro-layers specifically designed for exceptional tear resistance. The result: 215 lbs/in break strength, 1,200 lbs% tear resistance, and GSA-certified “No Hazard” blast performance on tempered glass. When your facility demands the highest level of protection against forced entry, blast events, and catastrophic glass failure, Ultra S800 is the answer — delivering unmatched security while remaining optically clear and blocking 99.9% of UV rays.
Highlights
Proprietary micro-layered construction delivers 1,200 lbs% tear resistance — engineered to resist penetration, not just hold glass fragments together
Blocks 99.9% of harmful UV rays — the highest UV protection in the Safety & Security series, safeguarding occupants and interiors
Industry-leading 215 lbs/in break strength and 27,000 psi tensile strength — the strongest optically clear security film in the 3M lineup
Optically clear with just 3% haze — maximum security without sacrificing natural views or daylight
Achieves GSA Level 2 with “No Hazard” rating on tempered glass — the highest possible blast mitigation performance, independently tested and certified
Ideal for high-security facilities, government buildings, financial institutions, and commercial properties requiring top-tier protection
Tested against large missile impact (ASTM E1886/E1996) and pressure cycling up to ±100 psf — proven protection under extreme real-world conditions
Backed by a comprehensive warranty from 3M — trusted performance from the global leader in safety and security film innovation
3M Luminer Safety & Security Comparison
| Specification | Safety S40 Basic |
Safety S80 Enhanced |
Ultra S800 Maximum |
|---|---|---|---|
| Film Thickness | 4 mil (0.10 mm) | 8 mil (0.20 mm) | 8 mil (micro-layered) |
| Film Construction | Single ply | Multi (2) ply | Micro-layered |
| VLT (on clear glass) | 87% | 86% | 87% |
| UV Block | 99% | 99% | 99.9% |
| Tensile Strength | 25,000 psi | 25,000 psi | 27,000 psi |
| Break Strength | 100 lbs/in | 200 lbs/in | 215 lbs/in |
| Elongation at Break | >125% | >125% | 95% |
| Impact Resistance | 150 ft-lbs (CPSC Cat 1) |
400 ft-lbs (CPSC Cat 2) |
400 ft-lbs (CPSC Cat 2) |
| ANSI Z97.1 Rating | Class B | Class A (Unlimited) | Class A (Unlimited) |
| Bomb Blast Mitigation | — | GSA Level 2 (Minimal Hazard) |
GSA Level 2 (No Hazard on tempered) |
| Tear Resistance | — | — | 1,200 lbs% |
| Scratch Resistance | <5% haze increase | <5% haze increase | 3% Δ haze |
| Best For | Low-force impact, basic shatter protection |
Seismic, windstorm, blast mitigation |
Maximum security, blast & break-in deterrence |
Source: 3M™ Safety & Security Window Film Technical Data Sheets.
Solar properties measured on 1/4" clear glass. Film properties are nominal, not for specification purposes.
Specifications
| Application Temperature (Celsius) | 5 °C |
| Applications | Blast Mitigation, Break-in Deterrence, Forced Entry Delay, Impact Resistance, Security Enhancing, Tear Resistance |
| Brands | 3M™ Scotchshield™ |
| Film Thickness (Metric) | 0.203 mm (8 mil) |
| Film Construction | Micro-layered |
| Interior/Exterior | Interior |
| Performance Level | Maximum |
| Product Color | Transparent |
| Product Usage | Buildings, Windows |
| Substrates | Glass |
| Visible Light Transmittance (%) | 87 Percent |
| Overall Length (Metric) | 23 Meter, 30.48 Meter |
| Overall Width (Metric) | 1524 mm, 1829 mm |
